2. Your LaCie Biggest F800
page 14
LaCie Biggest F800
User’s Manual
RAID Level Switch Selectors – The RAID Level Switch Selectors consist of two switches, which are used to set the RAID
level. For more information, please see section 4.1. Setting The RAID Level
.
Serial/RS-232 Port – The Serial/RS-232 Port is used to connect the LaCie Biggest F800 to a terminal or a terminal-
equipped PC with terminal emulation software. The status of the LaCie Biggest F800 can then be viewed remotely. For
more information, please see section 6.2. Fir
mwar
e Updates
.
FireWire 800 Ports – This is where you plug in the FireWire 800 cable furnished with the drive. For more information,
please see sections 2.4.1. Cables & Connectors – Fir
eWire, 4.3.1. Connecting To A Host Computer – FireWire 800
and 8. FireWire Questions & Answers.
Hi-Speed USB 2.0 Port – This is where you plug in the Hi-Speed USB 2.0 cable furnished with the drive. For more
information, please see sections 2.4.1. Cables & Connectors – USB
, 4.3.1. Connecting To A Host Computer – Hi-
Speed USB 2.0 and 8. USB Questions & Answers.
Power Status Indicator – This LED indicates the power supply status. During normal operation, the LED will light Green;
the LED will be unlit when there is no power to the unit or the unit is turned off.
Power Supply Connector – This is where you plug in the AC adapter supplied with the drive. For more information,
please see section 4.2. Cr
eating An Array.
Fan Status Indicator – This LED indicates the status of the ventilation fan. During normal operation, the LED will remain
off; the LED will light Red if the ventilation fan has failed. For more information, please see sections 5.2.3.4. Fan Failur
e
Message and 5.2.5.3. Fan And Temperature Information.
Power Switch – The Power Switch is the main on/off switch for the LaCie Biggest F800.
Ventilation Fan – The Ventilation Fan help to keep your drive cool during operation. Be sure not to block these
openings when using your drive.
Caution!
To avoid overheating, the LaCie Biggest F800 should be installed in a well-ventilated area and in such
a way as to maintain sufficient airflow across the controller chips. Also ensure that the Ventilation Fan is
not obstructed.
Environmental Requirements:
Temperature: 0 – 35° C (32 – 95° F)
Operation Humidity: 5 – 95%, non-condensing
Storage Humidity: 5 – 75%, non-condensing
1
2
3
4
5
6
7
8
9
