6
WARNING
Large throat opening snap hooks should not be connected to standard size D-rings or similar objects. The reason for this is if the hook
orD-ringtwistsorrotates,thenthismayresultinaloadonthegateoftheconnector.Largethroatsnaphooksarespecicallydesigned
foruseonxedstructureelementssuchasrebarorcrossmembers.Theseareshapedinsuchawaythattheycannotcapturethegate
of the hook.
8. IMPORTANT RESTRICTIONS WHILE MAKING CONNECTIONS
• A snap hook should not be connected into a loop or thimble of a wire rope, or attached to it in any way that may
slack the wire rope.
• Do not make connections where the connector locking mechanism can come into contact with a structural member or other such
equipment as it may potentially unlock the connector and release the connection.
• To connect to a single or a pair of soft loops on a harness, a carabiner that can fully close and lock should only be used. Snap hooks
are not allowed for such connections.
• A carabiner may be connected to a loop or ring connector that is already occupied by a choker style connector. Snap hooks are not
allowed for such connections.
• DonotuseconnectorsonananchorageobjectasshowningureG.
5. COMPATIBILITY OF CONNECTORS
Connectors are considered to be compatible with connecting elements when they have been designed to work together in such a way that
their sizes and shapes do not cause their gate mechanisms to inadvertently open regardless of how they become oriented. Connectors
(hooks, carabiners, and D-rings) must be capable of supporting at least 5000 lbs. (23 kN).
All connectors must be compatible with all system components like anchorages, etc. Never use equipment which is not compatible as this
may cause the connectors to disengage unintentionally. All connectors must be compatible in shape and size. As per ANSI Z359.12 and
OSHA, only self-locking snap hooks and carabiners may be used.
6. CONNECTIONS USING CONNECTORS
Ensure that only self-locking snap hooks and carabiners are used with this equipment. All connections should be compatible in size,
shape and strength. The connectors used should be suitable to each application. Ensure that they are fully closed and locked while in use.
7. NEVER USE INAPPROPRIATE CONNECTIONS
• While using KStrong snap hooks and carabiners, they should not be connected as below:
• Two or more connectors should never be attached to a single D-ring.
• Never attach a connector that could result in a load on its gate.
• Connectorsshouldnotbeconnectedinafalseengagement.Itshouldbevisuallyconrmedthattheconnectorisfullyengagedto
the anchor point. Avoid conditions when features that protrude from the connectors catch on to the anchor, giving a false sense of
being connected.
• Connectors should not be connected to each other.
• Connectorsshouldnotbeconnecteddirectlytothewebbingortotheropelanyardortieback,unlessspecicallyallowedbythe
manufacturer.
• Connectors should not be connected to any object which does not allow the connector gate to close or lock. Anchor shapes
that allow roll out to occur should never be used for connection. If the anchor to which the snap hook or carabiner is attached
is undersized or irregular in shape, then this may allow for the gate of the connector to come in contact with the anchor, thereby
causing the connector to open up and possibly disengage from the anchor. This is known as roll out of the connector.
