NOTE
KStrong retrieval SRL-R’s are provided with a unique HYDRO-Seepage (HS) system. This system ensures that the component parts
inside the SRL-R casing are always kept dry. In the unlikely event of water seeping through the cable opening into the SRL casing, the
rubber knob, which is present on the opposite end, should be rotated & opened up to drain out this water.
Water clogging through cable
opening of block casing
Rotate the Rubber Knob
and pull it
Push the Rubber Knob
back to its place to seal
the opening
28. INSTALLATION AND USE OF KSTRONG Micron™
• KStrong Micron™ can be used in both mobile and stationary applications.
• For stationary application as a normal SRL application, connect the anchorage eye of the Micron™ (UFS351102 and UFS350002)
with a connector conforming to ANSI Z359.12-2009, to an overhead anchorage, and the snap hook of the Micron™ to the dorsal
D-ring of the full body harness of the user. The distance of the anchor point should not be more than 2 ft. above the dorsal D-ring
of the harness.
• For mobile application, connect the eye of the Micron™ (UFS354002) to the dorsal attachment D-ring of the full body harness with
the help of a connector/ carabiner conforming to ANSI Z359.12-2009, which is compatible with the SRL subsystem, and ensure that
the connector is locked. Now connect the rebar hook at the termination end of the Micron™ to the anchorage structure.
Technical Specification
How to use
How to use Micron™ as a single or twin lanyard with twin SRL Connector (UFC409151)
Model Material of Construction Minimum
Breaking Strength
UFC409151 Alloy Steel 5000 lbs.
Open connector by pushing the
locking lever and push button at
the end simultaneously.
Slide Connector through loosened
web straps placed below the
Dorsal D-ring, then pull straps tight.
Push the pin inside the grooves of
the connector to ensure locking.
