08
Do not attach more than one personal fall arrest system to the anchor point.
The anchorage end of the cross arm strap / wire rope sling must be kept as short as possible. Excess anchorage length
of cross arm strap / wire rope sling increases the length of a free fall.
KStrong cross arm straps and wire slings are designed to be used as a wrap around structural member like beams,
trusses, headers, etc. These structures should be strong enough to withstand a minimum load of 5000 lbs. Ensure that
the webbing of the cross arm straps does not come in contact with any sharp edges, rough structures, protruding nails
and fasteners, chemical and corrosive environment, petroleum products, heat sources, etc. All of these could cause
damage to the webbing, causing the cross arm strap to lose its strength. While the wire rope anchor slings can
withstand exposure to rough surfaces, their contact with sharp edges and rough surfaces should be kept to a minimum.
Before installing any anchor, it is important that a competent person verify that the underlying structure on which the
anchor will be installed is strong enough to withstand the impact of forces which will be experienced in the event of a fall.
WARNING
INSTALLATION OF KSTRONG CROSS ARM STRAPS
WARNING
PRE USE- INSPECTION CHECK OF THE CROSS ARM STRAPS
Inspect the anchor webbing strap for any cuts, frays, abrasion, puncture or contaminants. The D-ring to which the
attachment is made, should be thoroughly checked for cracks, bends, deformities, corrosion, cracks, cuts, elongation
etc. The D-ring should be perfectly round and should lay flat. Also inspect the stitching for any cuts, breaks or damages.
Thoroughly examine the inside of the webbing loops as well for any signs of damage. Thoroughly examine the wire rope
anchor slings for the presence of broken strands, frays, cuts, corrosion, rust, cracks, tears, abrasion, excessive
elongation, chemical attack, excessive wear, etc. Inspect ferrules for cracks or damage. The equipment should be
immediately removed from service if any of the above conditions are recognized.
Inspect all other components of the fall arrest, work positioning, rescue system that are to be used, as per the
manufacturer's instructions. Remove from use immediately if the equipment shows evidence of having arrested a fall,
or if it is unfit for further use. Do not attempt to repair the equipment on your own.
INSTRUCTIONS FOR USAGE OF KSTRONG CROSS ARM STRAPS
WARNING
Step 2: Pass the D-ring end through loop end of the cross arm strap and cinch
tightly.
Step 4: Use the D-ring to anchor the connecting element of the personal fall
arrest system.
INSTALLATION OF CROSS ARM STRAP
(Models: UFA20504 and UFA 20506)
Note: The label on the strap should face outwards, and the structure on to
which cross arm strap is to be looped must be free from sharp and abrasive
edges. If however, there is presence of sharp, abrasive surface on the
structure, then this should be covered with a suitable covering recommended
for such use.
Step 1: Loop the cross arm strap around a suitable and strong structure.
Step 3: Loop the entire strap around the underlying structure, so that there
remains no excess webbing. Each time while looping, pass the D-ring
through the webbing loop. Continue till all the excess webbing is used up.
Step-1 Step-2
Step-3
direction
of loading
