7Krowne • 100 Haul Rd. Wayne, NJ 07470 • krowne.com
Refrigeration Installation & Operating Manual
Model Description
BS36 36” Back Bar Cooler
BS60 60” Back Bar Cooler
BS84 84” Back Bar Cooler
BS108 108” Back Bar Cooler
DB36 36” Direct Draw Cooler
DB52 52” Direct Draw Cooler
DB60 60” Direct Draw Cooler
Model Description
DB72 72” Direct Draw Cooler
DB84 84” Direct Draw Cooler
DB108 108” Direct Draw Cooler
KPT36 36” Pass Thru Cooler
KPT52 52” Pass Thru Cooler
KPT60 60” Pass Thru Cooler
KPT72 72” Pass Thru Cooler
Model Description
KPT84 84” Pass Thru Cooler
NS52 52” Narrow Door Back Bar Cooler
NS72 72” Narrow Door Back Bar Cooler
PTSD60 60” Sliding Door Pass Thru Cooler
SD60 60” Sliding Door Back Bar Cooler
SD108 108” Sliding Door Back Bar Cooler
Model Description
BR48 48” Remote Back Bar Cooler
BR72 72” Remote Back Bar Cooler
BR96 96” Remote Back Bar Cooler
PLUG-IN-CORD
115 VOLTS 15 AMPS RECOMMENDED
TO THE CONDENSING UNIT
EVAPORATOR FAN MOTOR, 2 SPEED(BS36 BLACK
WIRE NOT CONNECTED TO RED (1 SPEED))
BLACK
WHITE
RED
BLACK
BLACK
BROWN BROWN
WHITE
RED BLACK
BLUE
LED LIGHTS
(2 PER DOOR)
RED (+DC)
BLACK (-DC)
12VDC
LED
POWER
SUPPLY
LIGHT SWITCH
TEMPERATURE
PROBE
8
9
7
6
4
3
DIGITAL
TEMPERATURE
CONTROL
PIN&SOCKET
CONNECTOR
4 WIRE FEMALE
RECEPTACLE
PIN&SOCKET
CONNECTOR
4 WIRE MALE PLUG
GROUND
POWER SWITCH
10
DEFROST PROBE
MULLION HEATER( 1 PER POST)
EVAPORATOR FAN MOTORS
(3 MOTORS 96" MODEL)
LED LIGHTS
(2 PER DOOR)
RED (+DC)
BLACK (-DC)
LED
12VDC
POWER
SUPPLY
LIGHT SWITCH
GROUND
115VAC
Note:
Field wiring to the cabinet
and from the cabinet to the
condensing unit must comply with
all local and electrical codes
BLACK
WHITE
GROUND
CONNECTION BLOCK
(right/left side of
evaporator housing
remove cover)
WHITE
BLACK
GREEN
PURPLE
SOLENOID
VALVE (IF USED)
RED
PIN & SOCKET CONNECTOR 4
WIRE FEMALE RECEPTACLE
PIN & SOCKET CONNECTOR 4
WIRE MALE PLUG
MECHANICAL
THERMOSTAT (IF USED)
RED
BLACK
WHITE
GREEN
Wire Diagrams
