Kramer Electronics Ltd.
CL-8P – Installation Guide
6
• Plug the terminal connector into the socket.
• Secure the speaker cable using the supplied zip tie.
• Set the transformer tap to the desired setting.
• Attach the magnetic grille to the grille securing hook and place it into position
Wiring the Speakers – best practice
Your passive speaker features both low impedance (8Ω) and high impedance (70V/100V)
modes. Understanding the difference is essential for safe installation and optimal
performance.
Low Impedance Installation (8 Ohms)
Description:
In low impedance setup the speaker is connected directly to a low-impedance amplifier
(typically rated at 4Ω, 8Ω, or 16Ω). This method is commonly used in small to medium-sized
rooms where the amplifier is near the speakers, such as meeting rooms, boardrooms, or
home studios.
Note: In low impedance mode the CL-8P has an impedance of 8Ω.
Key Features:
• Higher sound quality due to full-range signal.
• Limited cable runs (usually less than 20 meters).
• One amplifier channel per speaker or a pair of speakers.
High Impedance Installation (70V / 100V)
Description:
This method uses a transformer to distribute audio over long distances using thin speaker
cables. Ideal for large areas or multi-speaker installations such as retail stores, restaurants,
schools, or outdoor spaces.
Key Features:
• Supports multiple speakers on a single amplifier channel, installed in parallel.
• Long cable runs (up to hundreds of meters) without significant loss.
Note:
In high impedance mode the CL-8P supports the following power
ratings:
o @100V -60W /30W / 15W
o @ 70V -60W / 30W / 15W / 7.5W
