Kramer Electronics Ltd.
CL-8P – Technical Specifications
15
Technical Specifications
Model
CL-8P
Audio Specifications
Drivers
LF Driver
200 mm (8 in) high output driver with polypropylene cone and
rubber surround
HF Driver
25mm (1") soft dome with dampening, ferrofluid — cooled
Frequency Characteristics
Frequency Range (-10dB)
55Hz-20kHz
Frequency Response (±3dB)
70Hz-20kHz
Power Handling
Power Handling
60W continues / 90W peak
Impedance
8Ω
Multi tap transformer settings
70V: 60W / 30W / 15W / 7.5W
100V: 60W / 30W / 15W
Acoustical parameters
Sensitivity (1W@1m)
90dB
Maximum continuous SPL (dB) @1m
Continuous: 103dB SPL / Peak: 105dB SPL
Dispersion
82° conical dispersion (1 kHz to 4 kHz)
Mechanical specifications
Installation
Type
In–ceiling speaker installation with brackets and C–ring
Mounting
4–point screw down Dog–Ear clamp, up to 60mm / 2.36” ceiling
thickness
Connectors
4–pin pluggable Euroblock connector, 28–12AWG
Weight per single speaker
6.23kg (13.74lbs)
Dimensions
Depth (ceiling clearance)
270mm / 11.7”
Back enclosure outer diameter
295mm / 11.6”
Cutout diameter
297mm / 11.7”
Grill diameter
327mm / 12.9”
Shipping
Single box dimensions (single unit):
430mm x 430mm x 338mm / 17" x 17" x 13.3"
Master box dimensions (single unit)
438mm x 438mm x 351mm / 17.3" x 17.3" x 13.9"
Single Box weight
8.5KG / 18.8lbs
Master box weight
9.2KG / 20.3lbs
Packaging
Eco-friendly mono-material packaging made entirely from
recyclable cartons, designed for durability and ease of recycling
Materials
Grill
Black/White Powder Coated Steel, Magnetic, with cloth,
paintable, removable logo
Baffle
V-0 Flame Retardant
Back Enclosure / Cabinet
Powder–coated steel
Environmental
Operating Temperature:
-5°C to +50°C (23°F to 122°F)
Storage Temperature:
-10°C to +55°C (14°F to 131°F)
Humidity
30% to 85%, RHL non-condensing
Regulatory Compliance
Safety
UL1480A, UL2043, CE, UKCA
Environmental
RoHS, REACH, WEEE
