Kramer Electronics Ltd.
CL-6P – Technical Specifications
15
Technical Specifications
Model
CL-6P
Audio Specifications
Drivers
LF Driver
165 mm (6.5”) driver with polypropylene cone and rubber
surround
HF Driver
19 mm (0.75 in) liquid cooled soft–dome tweeter
Frequency Characteristics
Frequency Range (-10dB)
70Hz-20kHz
Frequency Response (±3dB)
80Hz-18kHz
Power Handling
Power Handling
30W continues / 45W peak
Impedance
8Ω
Multi tap transformer settings
70V: 30W / 15W / 7.5W / 3.8W
100V: 30W / 15W / 7.5W
Acoustical parameters
Sensitivity (1W@1m)
88dB
Maximum continuous SPL (dB) @1m
Continuous: 103dB SPL / Peak: 105dB SPL
Dispersion
106
o
Mechanical specifications
Installation
Type
In–ceiling speaker installation with brackets and C–ring
Mounting
4–point screw down Dog–Ear clamp, up to 60mm / 2.36” ceiling
thickness
Connectors
4–pin pluggable Euroblock connector, 28–12AWG
Weight per single speaker
3.75kg (8.27lbs)
Dimensions
Depth (ceiling clearance)
220mm / 8.66”
Back enclosure outer diameter
250mm / 9.84”
Cutout diameter
252mm / 9.92”
Grill diameter
282mm / 11.1”
Shipping
Shipping Dimensions (single unit)
400mm x 400mm x 298mm / 15.8" x 15.8" x 11.8"
Number of units in the master box
2
Shipping Dimensions in master box
410mm x 410mm x 618mm / 16.14" x 16.14" x 24.33"
Shipping weight (single unit)
5.42KG / 11.95lbs
Shipping weight master box
11.62KG / 25.62lbs
Packaging
Packed as single, 2 singles packed in a master box
Packaging Materials
Eco-friendly mono-material packaging made entirely from
recyclable carton, designed for durability and ease of recycling
Materials
Grill
Black/White Powder Coated Steel, Magnetic, with cloth,
paintable, removable logo
Baffle
V-0 Flame Retardant
Back Enclosure / Cabinet
Powder–coated steel
Environmental
Operating Temperature:
-5°C to +50°C (23°F to 122°F)
Storage Temperature:
-10°C to +55°C (14°F to 131°F)
Humidity
30% to 85%, RHL non-condensing
Regulatory Compliance
Safety
UL1480A, UL2043, CE, UKCA
Environmental
RoHS, REACH, WEEE
