Kramer Electronics Ltd.
CL-4P – Technical Specifications
15
Technical Specifications
Model
CL-4P
Audio Specifications
Drivers
LF Driver
100 mm (4”) high output driver with polypropylene cone and
rubber surround
HF Driver
19 mm (0.75 in) liquid cooled soft–dome tweeter
Frequency Characteristics
Frequency Range (-10dB)
90Hz-18kHz
Frequency Response (±3dB)
110Hz-18kHz
Power Handling
Power Handling
20W continues 30W peak
Impedance
8Ω
Multi tap transformer settings
70V: 20W / 10W / 5W / 2.5W
100V: 20W / 10W / 5W
Acoustical parameters
Sensitivity (1W@1m)
87dB
Maximum continuous SPL (dB) @1m
Continuous: 100dB SPL / Peak: 102dB SPL
Dispersion
125
o
Mechanical specifications
Installation
Type
In–ceiling speaker installation with brackets and C–ring
Mounting
3–point screw down Dog–Ear clamp, up to 60mm / 2.36” ceiling
thickness
Connectors
4–pin pluggable Euroblock connector, 28–12AWG
Weight per single speaker
2.18kg (4.81lbs)
Dimensions
Depth (ceiling clearance)
100mm / 4”
Back enclosure outer diameter
203mm / 8”
Cutout diameter
205mm / 8.1”
Grill diameter
232mm / 9.1”
Shipping
Shipping Dimensions (single unit)
320mm x 320mm x 166mm / 12.6" x 12.6" x 6.6"
Number of units in the master box
2
Shipping Dimensions in master box
330mm x 330mm x 348mm / 13.0" x 13.0" x 13.7"
Shipping weight (single unit)
3.28KG / 7.23lbs
Shipping weight master box
6.95KG / 15.4lbs
Packaging
Packed as single, 2 singles packed in a master box
Packaging Materials
Eco-friendly mono-material packaging made entirely from
recyclable carton, designed for durability and ease of recycling
Materials
Grill
Black/White Powder Coated Steel, Magnetic, with cloth,
paintable, removable logo
Baffle
V-0 Flame Retardant
Back Enclosure / Cabinet
Powder–coated steel
Environmental
Operating Temperature:
-5°C to +50°C (23°F to 122°F)
Storage Temperature:
-10°C to +55°C (14°F to 131°F)
Humidity
30% to 85%, RHL non-condensing
Regulatory Compliance
Safety
UL1480A, UL2043, CE, UK CA
Environmental
RoHS, REACH, WEEE
