121
© 2021 KOSTAL Solar Electric GmbH
Technical data
Power class 30 50 60
DC conductor cross section (min-max) mm² 4 … 6
Max. fuse protection on output side according to
IEC60898-1
B63 / C63 B125 / C125 B125 / C125
Internal operator protection in accordance with
EN 62109-2
RCMU/RCCB type B
Independent disconnection device according to
VDE V 0126-1-1
H
Height / width / depth mm 470 / 555 / 270 710 / 855 / 285
Weight kg 41 83
Cooling principle – regulated fans
H
Max. air throughput m³/h 185 411
Noise emission (typical)
4
dB(A) 50 < 63
Ambient temperature °C -25 … +60
Max. operating altitude above sea level m 4000
Relative humidity % 0…100
Connection technology, DC side Amphenol plug H4
Connection technology on AC-side (stud)
M6 M8
Interfaces
Ethernet LAN TCP/IP (RJ45) 2
WLAN
H
RS485 1
Digital inputs 4
Warranty
KOSTAL Smart Warranty / Warranty Years 5 (2)
Directives / Certification
EN 62109-1, EN 62109-2, VDE AR-N 4105:2018, PO 12.2, RD 244:2019, UNE 217001, EN 50549-1-2, CEI0-16 2019,
CEI0-21 2019 >11,08 kW, UK G99/1-4 LV, IRR-DCC MV 2015, IEC 61727/62116
