12
• To avoid accidental contact with the overheated bottom of the cooktop or unexpected
electrical shocks during operation, it is necessary to install a wooden insert. This insert
should be fixed with screws at a minimum distance of 50mm from the bottom of the
cooktop. Follow the requirements outlined below.
Warning:
• There are ventilation holes around the perimeter of the cooktop. You must ensure these
holes are not blocked by the worktop when installing the cooktop.
• The glue used to bond plastic or wooden materials to the cabinetry must withstand
temperatures of at least 150°C to prevent the panels from detaching.
• The rear wall and adjacent surfaces must be capable of withstanding temperatures up
to 90°C.
After Installation
After installing the cooktop, ensure that:
• The power cord is not accessible through cupboard doors or drawers.
• There is adequate airflow of fresh air from outside the cabinetry to the base of the
cooktop.
• If the cooktop is installed above a drawer or cupboard space, a thermal protection
barrier is installed below the base of the cooktop.
• The isolating switch is easily accessible to the user.
Before Locating the Fixing Brackets
The cooktop should be placed on a stable, smooth surface (use the packaging). Do not
apply force onto the controls protruding from the cooktop.
Min. 50mm
Max. 5mm
Ma
x. 5mm
