12
4. Place the bracket (A) over the holes that match the size of the screws. There is one
set of screw holes in each corner of the cooktop. Slightly tighten a screw (B)
through the bracket (A) so that the corner bracket is attached to the cooktop, but
so that you can still adjust the position.
5. Carefully turn the cooktop back over and then gently lower it into the aperture hole
that you have cut out.
6. On the underside of the cooktop, adjust the brackets into a position that is suitable
for your worktop. Then fully tighten the screws (B) to secure the cooktop into
position.
Sealing strip
(B) Screw
(A) Bracket
