14
English
Size - A5
Fig.
9
Select the desired operating mode
using the MODE button.
Mode Function
Standard fan function
Adjustable fan strength,
which simulates natural
wind.
Comfort mode, display
turns o automatically
approx. 30 seconds after
the last use. The previously
set mode is unaected,
by this.
Fig.
10
Press the Swing button to turn the
swivel function on and o.
Timer mode
The timer
function switches the ventilator
o at a set time. Times can be selected
between 1to 8 hour intervals.
Fig.
11
Press the TIMER button to set the
turn-o time.
Note: If the timer is activated, an H will
appear in the display below the °C unit.
Description Symbol Value Unit
Maximum fan flow rate F 13.5 m
3
/min
Fan power input P 44.3 W
Service value SV 0.3 (m
3
/min)/W
Standby power consumption P
SB
0.4 W
Fan sound power level L
WA
59 dB(A)
Maximum air velocity c 2.7 m/s
Measurement standard for service value IEC 60879:1986+cor1:1992
Contact details for obtaining more information Imtron GmbH
Wankelstraße 5, 85046 Ingolstadt, Germany
Cleaning and care
Caution
• Before cleaning, always let the product
come to a complete stop and disconnect it
from the mains.
• Do not use solvents or abrasives, metal
utensils or hard brushes for cleaning.
• Do not immerse the fan in water or other
liquid. Do not allow water to drip on or
into the fan motor housing.
Fig.
12
Use a soft piece of cloth for cleaning. If
the dirt or contamination proves hard to
remove, use mild detergent.
Technical data
Rated voltage : 220 - 230 V~
Rated power : 60 W
Frequency : 50 Hz
Protection class : II
Height : 117 cm
Weight : approx. 3.7 kg
Remote control : 1 x CR2025
IM_KTFC6020_191106_V04_HR.indb 14 7/11/2019 09:45
