17
English
Fig.
7
Press the on/o button to turn on
the device. Set the temperature and
time individually with the +/- buttons.
The maximum temperature is 200°C,
the maximum time is 30min. Please
observe the symbols at the top of
the product as well as the following
table. The temperature and time or the
remaining time are displayed alternately
in the display. Press the on/o button
again briefly to start the process.
The operation indicator lamp and the
heating indicator light illuminate.
The set temperature is reached after
approx. 2 to 3 minutes. When the
preset temperature has been reached,
the heating indicator light turns o.
During subsequent heat-up processes,
the heating indicator light switches on
again and again. When the time is up,
a beep sounds repeatedly and the unit
turns itself o. To turn o the hot air
fryer manually, press the on/o button.
Fig.
8
To remove the fried food, pull the frying
pan out of the appliance by the handle.
Place the frying pan on a flat and heat-
resistant surface.
Fig.
9
Put the fried food in a suitable bowl or
on a plate. If necessary, use a wooden
spatula to empty the frying pan.
When all parts have cooled down,
clean the device as described under
Cleaning and Care.
Note:
• The fat that leaked from the foods during
the frying process will gather below the
frying grate. Use a wooden spatula to
remove the prepared foods, in order to
avoid that this fat is poured on top of the
foods.
• The heating indicator light will turn itself
on and o during the frying process. This is
a normal occurrence and indicates that the
set temperature is being kept.
Installation
Fig.
1
Place the product on an even, solid and
heat resistant surface. Consider the
distance to the next socket outlet.
Note:
To ensure sucient air circulation follow
minimum clearances as given below:
Sides: 10 cm
Back: 30 cm
Up: 30 cm
Warning
The product must not be placed into
furniture. The product must not be placed
directly below a plate, cupboard or cabinet.
Operation
Fig.
2
Pull the frying pan out of the appliance
using the handle.
Fig.
3
Remove the transport rubbers from the
frying grate and put the frying grate
into the frying pan.
Warning
Be sure to remove the transport rubbers
from the frying grate. Failure to remove the
protective rubbers before usage might result
in fire and damage to the equipment.
Fig.
4
Fill the food to be fried in the frying
pan, but at maximum up to the .
Fig.
5
Put the frying pan back into the
appliance. Make sure it fits correctly.
Fig.
6
Plug the mains plug into a suitable
socket.
