Positioning
The edges of the cooktop must be a minimum distance of 60 mm from any
combustible components of a side or rear wall. Note: This measurement is from
the wall to the edge of the appliance, not the edge of the cutout. If tiles are applied
to the rear wall the thickness of the tiles may be included in the 60mm
measurement.
The safety gap between the hob and the rangehood placed above must comply
with the recommendations of the rangehood manufacturer. In case of no
instructions, a minimum distance of 650mm (or other minimum distance as may be
specified by AS/NZS 5601 and interpreted by a certified installer) should apply.
400mm between the hob surfaces, providing that the underside of the horizontal
surface is in line with the outer edge of the hob. If the underside of the horizontal
surface is lower than 400 mm, then it must be at least 50 mm away from the outer
edges of the hob.
During appliance operation, a clearance distance of at least 50 mm should always
be maintained between the appliance and any combustible materials.
You must have a gap of at least 25 mm and at most 74 mm between the
underneath of the appliance and any surface that is below it.
o
o
o
o
o
CLEARANCES REQUIRED
WHEN FITTING THE COOKTOP
WITH A RANGEHOOD ABOVE
900mm
650mm
400mm
400mm
60mm
480mm
in
0
.
0mm
M
2
This appliance is to be built into a kitchen unit or 600mm worktop,
providing the following minimum distances are allowed:
- An oven must have forced ventilation to install a cooktop above it.
- Check the dimensions of the oven in the installation manual.
- The cut out size must comply with the measurements indicated.
830mm
16
