PRODUCT OVERVIEW
1
Control panel
15
Lower air duct bottom
2
Horizontal louvre
16
Wire-winding post
3
Vertical louvre
17
Drain cap
4
Air outlet frame
18
Evaporator lter mesh
5
Vertical louvre connecting lever
19
Evaporator lter frame
6
Caster
20
Radiating ne mesh
7
Top cap
21
Condenser lter mesh
8
Horizontal louvre connecting lever
22
Condenser lter frame
9
Main vertical louvre
23
Base plate
10
Front shell
24
Remote control
11
Handle position (right side: remote
control storage area)
25
Exhaust hose short connector
12
Back shell
26
Heat exhaust hose
13
C-shaped buckle of the heat exhaust
hose snap
27
Sealing board assembly
14
Power cord
28
Circular connector
