34
EN
INSERTING AND FIXING THE HOB
Before inserting the cooktop into the worktop, place the adhesive
around the bottom edge of the hob. It is important that this
evenly, without gaps or overlaps, to prevent liquids from seeping under the hob.
1. Place the seal around the bottom edge of the hobs as shown in the diagram.
2. Place the hob in the installation opening and push it down so that the hob is
ush with the cabinet.
3. Secure the hob in place using the xing brackets supplied.
Secure the hob to the underside of the worktop using the xings provided. Screw
one end of the bracket into the pre-drilled holes in the underside of the hob,
the other end of the bracket should be under the worktop to secure the hob in
position.
The minimum height of all adjacent units (including light pelmets) is 450 mm
unless they are made of a re-resistant material (e.g. steel, ceramic tiles).
There must be no overhanging surface and no hood or fume extraction system
within 600mm of the burner tops. Leave at least 50 mm between the base of the
appliance and any combustible surface. Do not leave packing materials (plastic
bags, nails, polystyrene foam, etc.) within the reach of children, as they are a
potential source of danger.
The hob is tted with a special seal to prevent liquids from entering the housing.
Follow these instructions to use it correctly.
seal
hob
screw
Worktop
Fixing bracket
