37
Installation of the cooker hood
EN
Requirements according to the operating modes
The installation requirements with regard to the structural
conditions depend on the desired operating mode.
The appliance can be used in one of the following
operating modes:
• Recirculation mode with return of the exhaust air into the room
• Exhaust air operation with air ducting to the outside through
an air duct or a permanently installed exhaust air pipe
Also refer to the corresponding sections under "Functionality ..."
Notes for recirculation mode
If you use the appliance as a recirculation hood,
no special structural measures or requirements are necessary.
However, please note the following:
• Make sure that the supplied and pre-assembled
activated carbon fleece filter is inserted or replace it
if necessary, as described in the corresponding
section under "Cleaning and maintenance".
Note: Be aware that a carbon filter is basically used
to bind odours in recirculation mode, but the filter fleece
also supplements the metal filter in terms of filter performance!
Do not use the appliance without the filters in place
to avoid the risk of fire, damage and malfunctions
as a result of grease deposits!
• For the exhaust air duct via the ventilation slots on the front edge
of the top of the appliance (1), the deflector pre-installed
on delivery must be removed from the fan motor;
for the exhaust air duct via the exhaust air opening on the rear edge
of the top of the appliance (2), the deflector must be inserted
and the exhaust air connection piece must be fitted to the rear
air outlet, as described in the relevant section under
"Installation preparation ...".
• The exhaust air should be able to flow away from the appliance
upwards (for under-cabinet installation, in front of
or through the interior of the furniture above).
When mounting, make sure that the corresponding
ventilation slots are not covered and that the exhaust air ducts
are not blocked.
2
1
