46
Installation of the cooker hood
• For exhaust air operation, attach an exhaust air hose
(diameter 150 mm) in the cut-out on the air outlet
of the cooker hood
and connect it to the exhaust air opening.
• Make sure that the metal grease filter is fully reinsert-
ed before using the appliance.
Wallmounting
For installation on solid masonry,
proceed as described below.
If the appliance is to be mounted on a different type of wall
(e.g. plasterboard, aerated concrete, poroton brick),
replace the mounting material according to the substrate.
If the mounting surface is made of wood,
you can do this without the dowels.
However ensure a secure hold.
• Remove the metal filters from the hood,
lift the hood body and place it in the desired position
on the wall.
• Mark the drill holes on the wall from the inside of the
hood and put the hood down again.
• Drill holes at the marked points
according to
the length + 10 mm and the diameter
of the dowels
.
• Then carefully tap the dowels into the drill holes
with a hammer and screw in the screws,
but not completely yet.
