52
Installation of the cooker hood
• Tap a dowel into each drill hole, place the two brackets
for the shaft parts in the position described before
and fasten them to the wall by screwing the other
ST4×30 screws into the dowels and tightening them.
• Place the telescopic exhaust air shaft on the hood
body again, hooking the top end of the outer (lower)
part into the lower shaft bracket in a downwards
direction.
Make sure that the lower end of the outer shaft part
is flush with the hood body.
However, a screw connection of the shaft
with the hood body is not necessary.
• Pull the upper edge of the inner (upper) shaft part
to the required height and attach it to the upper
shaft bracket using the ST4×8mm screws supplied.
• Before using the appliance, make sure that
the previously removed metal grease filter
is fully reinserted
and that the edge extractor plate is folded in
securely in the holder again!
• Install the supplied non-return valve in the exhaust air
outlet on the top of the hood body with the opening
direction of the flaps upwards.
Note: For recirculation mode or if the room's
exhaust air duct already has a non-return valve,
this step is not necessary.
• Attach the supplied exhaust air hose to the air outlet
of the hood body and connect it to the further
exhaust air duct.
Note:
This step is not necessary for recirculation mode.
