12
Megapixel Helios
HELIOS Software
The Megapixel HELIOS video processor is controlled via a web browser.
There is no software to install. Open your favorite web browser and enter the
IP address shown on the front screen of the HELIOS. Multiple users can be
logged in at the same time.
For more information visit www.megapixelvr.com.
Megapixel Helios Overview
Management Port IP Address shown on front screen
Video Preview
Push Button / Encoder
Power Switch, Fuse and IEC Input: 100 – 240VAC, Internal Redundant
Ethernet Management Port (Connect to Computer)
8k Input pixel map
Display Port (Optional x2)
HDMI (Optional x2)
SDI Module – Not Included - 4 Shown (Optional up to 4)
SMPTE 2110 Fiber SFP (Optional up to 4)
Ethernet outputs:
HELIOS Jr: 1G x8. Each 1G output can drive 30 MIMIKs in daisy chain.
HELIOS Standard: 10G Fiber SFPs (optional for larger pixel counts)
requires license upgrade and external Netgear switches can drive up
to 2400 MIMIKs.
Sync / Genlock
