4
Inserting Louver
Inserting Gel Frame
Applying Gel to Frame
Place the long edge of the Louver into the lower channel containing a set of
leaf springs. Press down on the Louver and slip the upper edge of the louver
into the upper channel of the ixture. To remove, reverse the procedure.
The gel frame is secured to the ixture by 4 spring-loaded pins. Align the pins of the
gel frame with the oval receptacle holes on the edge of the ixture. Pull back the
pins and release into the receptacles to properly secure the gel frame.
A) The Gel Frame comes with gel clips. Cut the gel or diffusion to size and use the
clips to fasten to the frame.
Note: It is recommended to attach one clip on all four sides and two clips near all
four corners of the Gel Frame.
B) Another method is to apply transfer tape directly to the gel frame.
The clips are not necessary when taping the gel.
