5
FreeStyle Harness
FreeStyle Harness:
Align arrows on harness connector with
tube. Push and click into place. To remove
harness connector, turn locking ring to the
left and pull.
Push tubes into the ixture’s tube holder
clips. The tubes can operate independent
of the ixture allowing them to be built
into sets or custom soft boxes or hand-
held as a single tube for an eye-light.
To Release the Tube Harness
Rotate the ¼ turn fastener clockwise to
release harness.
The harness connects directly to the
controller. Connect the harness to the
controller. Align the key ways on the
harness connector with the oval Logo at
the top with the circular receptacle on the
ballast. Rotate the silver locking ring until
it clicks into the lock position.
