Copyright@2024 KILOVIEW Electronics Co., LTD
P3 5G Wireless Bonding Encoder·User Manual
5
4 Equipment Installation
Before using the multi-channel aggregation function, the P3 Mini device needs to correctly install the Nano-SIM card,
antenna and other accessories. The specific installation method is as follows:
4.1 Installing the SIM card
The three Nano-SIM card slots shown in the left picture can be used to install SIM cards.
The installation steps are as follows:
1. As shown in the left picture, align the notched corner of the SIM card with the slot to
be inserted.
2. Push the SIM card to the bottom and make sure the card is firmly fixed in the slot.
After the installation is complete, insert the SIM card and wait for about 1 minute. The
device will automatically detect the connected card slot signal. If the signal is normal, it
means that the SIM card is installed successfully.
To remove the SIM card, follow these steps:
1. As shown in the left figure, use a push pin to gently push the SIM card inward until it
pops out.
2. Once the SIM card pops out, you can remove it.
4.2 Installing the Antenna
There are two types of external antennas for P3 Mini, namely Wi-Fi antenna and 4G
antenna. The installation method is as follows:
1. As shown in the left figure, align the SMA interface of the antenna with the
corresponding antenna interface of the device.
2. Tighten the antenna screw to ensure that the antenna is firmly connected.
Note: Wi-Fi antenna and 4G antenna cannot be mixed. Mixing antennas will cause
abnormal antenna signals. Please
carefully identify the silk-screen logo on the antenna when plugging in the antenna to
ensure correct installation.
[There is a specific plan for distinguishing antennas, but it has not been confirmed by Mr.
Zuo yet. Please confirm and write it into the manual as soon as possible]
Note:
⚫ Please use the device’s standard power adapter, standard PD charger or power bank to power the
device. Other unqualified power sources may damage the device.
⚫ Please install the Wi-Fi antenna and 4G antenna correctly. Incorrect antenna installation will significantly
affect the signal quality and performance of the device
