52" Tide / 52" Tide Weather+ | 13
ATTACHING THE FAN BLADES
CAUTION: To Reduce The Risk Of Electric Shock, Disconnect The Electrical
Supply Circuit To The Fan Before Installing Fan Blades.
Step 1. Attach blade to blade bracket using three blade screws and three
washers found in the hardware pack as shown. Do not tighten blade screws until
each screw has been started. Then, tighten each screw starting with the center
screw. (Fig. 18)
Repeat for remaining blades.
Step 2. Fasten blade assembly to the holes located on the bottom of the
flywheel. Tighten the two pre-installed motor screws in the blade bracket.
Repeat steps for the remaining blade assemblies. (Fig.19)
Fig. 18
Fig. 19
Blade Screw
Blade Washer
Blade
Blade Bracket
Flywheel
Blade Assembly
