Troubleshooting
15 16
Troubleshooting
ReasonMalfunction Phenomenon
Before maintenance
Start the washing machine from
Rinse Process, the washing
machine does not input the water
• The washing machine will start from the spin process in order to
spin out the water and detergent from the clothes, then input the
water (if there is water in the tub it will drain out the water rst)
The wash process changes from
Spin to Rinse
• When the clothes are not even or are on a single side of the tub,
the washing machine will input the water and make the clothes
balance and even
The control button is useless to
touch
• If want to change the PROCESS after the washing machine started,
please touch the Start/Pause button to reset the process
Spin delay • The washing machine will delay 15 to 60 seconds to enter spin
process after drain or after select spin process only
ChecklistProblem
Does not work • Is electricity present?
• Is the tap opened?
• Is the plug loose, or fuse broken?
• Turn on the power or start button?
Fail to ll water
For some troubles, the machine buzzer will ring and alarm, and the indicator will ash.
• Is the tap opened?
• Is the drain hose frozen?
• Is the water supply cut?
• Is the water inlet valve blocked?
ChecklistTroubles Display
Breakdown
Standing
drain
No display
The plug is badly connected to the
socket or the switch is not activated.
Solution
Connect the plug properly activate
the switch.
No display
No display
No display
E1
The socket is dead or the fuse is
broken.
The current process is lost for power
failure.
The voltage is too low or too high.
The drain hose is hung up over 90cm
or is blocked.
Contact the authorized technician.
Reuse only when power failure is
eliminated.
Remove the plug and reuse it when
the voltage comes to normality.
Check the drain hose, open the lid and
then close it to continue drain process.
ChecklistTroubles Indicator Light
Breakdown
Standing
drain
No indicator
The plug is badly connected to the
socket or the switch is not activated.
Solution
Connect the plug properly or activate
the switch.
No indicator
No indicator
No indicator
E1
The socket is dead or the fuse is
broken.
The current process is lost for power
failure.
The voltage is too low or too high.
• The drain hose is blocked;
• The drain hose is hung up over
90cm
Contact the authorized technician.
Reuse only when power failure is
eliminated.
Remove the plug and reuse it when
the voltage comes to normality.
Check the drain hose, open the lid and
then close it to continue the draining
process.
ChecklistTroubles Display
A conict
between
the tub
and the
cabinet
during
spinning
Insucient
water
supply
Abnormal
water level
sensor
E3
The clothes are not laid evenly in the
tub. The machine will try to make an
automatic check and adjustment for 2
times, or if nothing available, an alarm
will be given.
Solution
Open the lid, distribute the clothes
evenly in the tub and then cover it.
E4
E6
The tap is closed, water supply is cut
o or water pressure is too low, so the
water fails to reach to the desired level
for quite a long time.
The sensor fails for short or open
current, etc. and an alarm will be given.
Open the tap or use the machine after
the water pressure comes to normal.
Open the wash lid, close it and restart
to input water.
Contact the authorized technician.
Unstoppa-
ble inlet or
automatic
drain
E7
Abnormalities occur in computer
sequencer, inlet valve or water level
sensor.
Cut o the power after draining, and
try to contact the authorized
technician.
Fail to
power o
or power
on
No display
Computer sequencer is broken. Contact the authorized technician.
Spin
malfunction
E2
The lid is opened during spinning
(stop working and alarm), or used
under glaring sunlight.
Close the lid or use it indoors.
