Storm window
frame or other
obstruction.
SASH
1-1/2"min
(38 mm)
Board
thickness
as required,
for proper
pitch to rear,
along entire
sill. Fasten
with nails or
screws.
CAUTION: If storm window blocks AC,
Please install according to the figure above.
3
Lift the AC into the window
RIGHT
LEFT
Once the AC is centered and the bottom bar is
successfully positioned, close the window down
onto the AC, behind the top bar. See diagram
above. Pull the panels to the side of the window.
Close the window down
onto the AC, and pull the
panels to the side of the
window
16
