521 East 3
rd
Street Mt. Vernon, NY 10553 • www.keydigital.com
Rev 1.1 – Dec, 2022
12
HDMI Inputs (4): Using an HDMI cable, connect your HDMI sources.
• Supports up to UHD/4K @ 60fps [4:2:0], 8 bit color, 10.2Gbps maximum bandwidth
• Compliant with HDMI 2.0, HDCP 2.x and previous
• Supports surround audio formats including Dolby ®, DTS™ (formats up to 5.1 / 6.1)
• Does not support HDR, CEC, ARC, or 3D
• For Display Port sources use active DP to HDMI converter
• Blue Link LED to the right of port illuminates with an active HDMI signal from source.
HDMI Outputs (4): Using an HDMI cable, connect your HDMI displays.
• Supports up to UHD/4K @ 30fps [4:4:4], 8 bit color, 10.2Gbps maximum bandwidth
• Compliant with HDMI 2.0, HDCP 2.x and previous
• Supports surround audio formats including Dolby ®, DTS™ (formats up to 5.1 / 6.1)
• Does not support HDR, CEC, ARC, or 3D
• Output resolution of 4K @ 30fps, 1080p @ 60fps, or 720p @ 60fps may be selected per output using
KDMS Pro software or by sending command via TCP/IP or RS-232
• For Display Port monitors use active HDMI to DP converter
• Blue Link LED to the right of port illuminates with active Hot Plug Detection voltage from the display.
UHDoTP Output (4): Connect a CAT5e/6 cable to the Rx unit’s UHDoTP Input port using CAT5e/6 cabling in
568-B termination.
• Supports up to UHD/4K @ 30fps [4:4:4], 8 bit color, 10.2Gbps maximum bandwidth
• Compliant with HDMI 2.0, HDCP 2.x and previous.
• Distance performance:
o UHD/4K: Up to 115ft (35m) using CAT5e/6, up to 40m (131ft) using CAT6A STP
o 1080p: UP to 164 ft (50m) using CAT5e/6, up to 60m (197ft) using CAT6A STP
• Supports Dolby®, DTS™ (5.1 / 6.1 formats max)
• Does not support HDR, CEC, ARC, or 3D
• Output resolution of 4K @ 30fps, 1080p @ 60 fps, or 720p @ 60fps may be selected per output using
KDMS Pro software or by sending command via TCP/IP or RS-232
• Provides 12V Power over CAT to each KD-EXMLVRx
• Blue Link LED to the right of port illuminates with active link with KD-EXMLVRx unit
• Important Notes:
o Minimum CAT5e/6 cable length required: 17ft (5m)
o Not compatible with HDBaseT or third-party Rx. Connecting to incompatible Rx may cause
damage and result in void of warranty.
Analog Audio Outputs (4): 6-pin phoenix balance / un-balanced
• Provides 2ch balanced or un-balanced analog audio output from the selected HDMI input source.
• The Pin assignment for the audio is as follows:
o Left + is Pin 1; Left - is Pin 3; Left Ground is Pin 2.
