16

-- Service : Baud Rate=115200bps, Data=8bit, Parity=None, Stop=1bit --

-- Front Panel Button : Enabled , CAMUSB Control Mode : 0 --

-- --

-- Network Setting(Web Server/TCP Control) Status --

-- MAC Address = 60:89:B1:36:00:01 --

-- Host IP Address = 192.168.001.239 --

-- Net Mask = 255.255.255.000 --

-- Router IP Address = 192.168.001.001 --

-- TCP Port = 0023 --

-- --

-- Video Input Status --

-- EDID = DEFAULT 10, FORCED HPD = ON , AUTO SENSE = OFF --

-- 01 : HDMI1, LINK = ON --

-- 02 : HDMI2, LINK = OFF --

-- --

-- Video Output Status (D=Disable, E=Enable) --

-- HDMI Output : IN = 01, OUT = ON , V/MUTE = D, LINK = ON , DBG = OFF --

-- HDBT Output : IN = 01, OUT = ON , V/MUTE = D, LINK = ON , DBG = OFF --

-- LRM = OFF --

-- --

-- Display Output Status (CEC Control) --

-- HDMI Output : TV = ON , A/V MUTE = Disable, A/MUTE = Disable --

-- HDBT Output : TV = ON , A/V MUTE = Disable, A/MUTE = Disable --

-- --

-- Audio Output Status --

-- Audio Output : IN = Video 01 , Balanced = Enabled, PCM = Enabled --

-- AMP220 Mode = OFF, MIC Mode = OFF --

-------------------------------------------------------------------------

Specifications

Technical:

» Inputs: 2 HDMI, 1 IR Sensor, 1 Bi-Directional RS-232

» Outputs: 1 HDBaseT RJ45, 1 Bi-Directional RS-232, 1 IR output

» DDC Signal (Data): Input DDC Signal: 5 Volts p-p (TTL)

» HDMI Video/Audio Signal: Input Video Signal: 1.2 Volts p-p

» RJ45 Connector: Shielded Link Connector, HDBaseT

» IR Connectors: 1 IR sensor 3.5mm, 1 IR emitter 3.5mm

» RS-232 Connector: 3-pin phoenix terminal

General:

» Regulation: CE, RoHS, WEEE, EAC; Enclosure: Black Metal

» Product: 5.5 x 4.1 x 1.43” (200.3 x 153 x 25.4mm), Weight: 1 lbs

» Packaging: 11” x 7.9” x 2.1” (250 x 195 x 90 mm), Weight: 2.1 lbs

» Accessories: KD-PS50W48VC 50W power supply (48V/1.04A) (qty1); IR sensor (qty 1); IR emitter

(qty 1); L-Bracket (qty 2); Ear Mount Screw (qty 4); 6-pin phoenix terminal (qty 1); 3-pin phoenix

terminal (qty 1); 6 ft USB Micro cable (qty 1); 6 ft USB A to B data cable (qty 1)
