45
TECHNICAL SPECIFICATIONS
Operating voltage / frequency (V/Hz (220–240) V~/50Hz
Total current (A) 10
Water pressure (Mpa) Maximum: 1 Mpa Minimum : 0.1 Mpa
Total power (W) 1850
Maximum dry laundry capacity (kg) 7
Spinning revolution (rev / min) 1200
Programme number 15
Dimensions (mm)
Height
Width
Depth
845
597
416
CHAPTER 3. INSTALLATION
REMOVING THE TRANSIT BOLTS
3
2
4
1.
Before operating the washing
machine, remove the 4 transit bolts
and rubber spacers from the rear
of the machine. If the bolts are not
removed, they may cause heavy
vibration, noise and malfunction of
the machine and void the warranty.
2.
Loosen the transit bolts by turning
them anticlockwise with an
appropriate spanner.
3.
Remove the transit bolts with a
straight pull.
4.
Fit the plastic blanking caps
supplied in the accessories bag into
the gaps left by the removal of the
transit bolts. The transit bolts should
be stored for future use.
NOTE
Remove the transit bolts before using the machine for the first time. Faults occurring due to the
machine being operated with transit bolts fitted are out of the scope of the warranty.
