27
5. Fix the outside chimney bracket on the outside chimney, and be sure that the inside chimney can be
adjusted the height in it freely. See Pic 4.
6. Put the cooker hood on the hook and put the chimneys on the cooker hood. Then fix the body with safety
screw. Note: The two safety vents are positioned on the back housing, with diameter of 6mm. See Pic 5.
Pic. 4
Pic. 5
inside chimney
outside chimney bracket
outside chimney
7. Adjust the height of the inside chimney to the position of the
inside chimney bracket and fix on it by screw. See Pic 6.
Pic. 6
safe screws
