28
6. Install the outside chimney bracket onto the outside chimney with 2pcs ST4*8mm
screw, make sure the inside chimney can be flexed freely.See Pic 4.
7. Make the hood hang on the wall in the fixed position, adjusting the cooker hood position, fix the cooker
hood with 2pcs ST4*30mm safety screws. Note: The two safety vents are positioned on the back housing,
with a diameter of 6mm.See pic 5.
8. Adjust the height of the inside chimney to the position of the inside chimney bracket and fix it with 4pcs
ST4*8mm screws.See Pic 6.
Pic. 4
Pic. 5
Pic. 6
inside chimney
outside chimney bracket
outside chimney
