40 OBN-13-BA-e-2511
Assembly
The following steps must be carried out in order to correctly assemble the fluorescence
incident light unit or mount it on the microscope housing.
1. If the microscope is already set up without the FL unit, the microscope head must
first be removed.
2. Turn the main part of the FL unit to the side and screw the protective plate to the
appropriate position on the underside.
3. Attach the main part of the FL unit to the designated connection point on the
microscope housing and secure it with the fixing screw.
4. Bring the lamp housing and the main part together via the connection points and
fasten with both fixing screws.
5. Attach the microscope head to the main part of the FL unit and secure it with the
fixing Allen screw.
6. Install the connecting cable between the lamp housing and the power supply unit.
7. Establish the power connection using the mains cable.
Operation
Before the reflected light unit is put into operation for special fluorescence applications,
it is advantageous to set up the microscope in bright field mode. This includes sample
placement, setting the interpupillary distance, pre-focusing, diopter compensation, etc.
You can then proceed to use the fluorescence reflected light unit.
1. When using a HBO lamp at first there must be ensured, that the control lever
for the illumination is slid-in.
2. Establish the power supply. When using a HBO lamp, check the setting of the
input voltage by using the appropriate slide on the rear of the power supply
unit (100V/240V).
3. Press the main switch. When using a HBO lamp, you have to press the
ignition after that in order to illuminate the lamp. It lasts about 15 minutes until
the lamp has gained a maximum and stable illuminating power.
4. After placing the sample you can bring the needed objective into the beam
path.
5. Choose the right position of the control wheel for the FL module.
6. When using a HBO lamp, now the control lever for the illumination can be
pulled out.
7. Start the observation.
