5
3 Slide the transceiver into the mounting bracket and secure it using the supplied
hex-headed screws.
4 Mount the microphone hanger in a location where it will be within easy reach
of the user.
• The microphone and microphone cable should be mounted in a place
where they will not interfere with the safe operation of the vehicle.
CAUTION
When replacing the fuse in the DC power cable, be sure to replace it with a fuse of the same value.
Never replace a fuse with one that is rated with a higher value.
M4 x 8 mm
Hex-headed screw
DC power cable
Mounting bracket
Antenna connector
Power input
connector
Fuse
Black (–) cable
Red (+) cable
12 V vehicle
battery
Microphone
5 x 16 mm Self-tapping
screw
Spring
washer
Flat
washer
