UFOpro User Guide
2
Name Range
Frequency (MHz) 950~14500
Symbol Rate(KSym/s) 1000~45000
UFO 111/4 >Service Configuration
Service Configuration page is where you can manage the received services and output them to their
designated interface. The configuration of all modules in UFO 101 is mostly the same.
First, you need to scan the port on each LOCKED TS. Each port might be scanned automatically or
needed to be scanned manually when its source is changed.
After scanning each channel, you can start to configure the services. You need to click Apply button
after you configure service to CAM for descrambling, otherwise the descrambling configuration will
not be saved. Then you can choose the services to be routed, you can output each service by clicking
the icon and below “Destination Settings”. You can route a whole stream or a service(s) from
the input channel toward the available output channels (IP or RF). Two types of routing are possible.
1. Bypass mode. In this mode, you can route a whole input transport
stream towards an IP or RF output which will be occupied only by this
stream. Any attempt of routing other stream/service towards this
channel will be an error. This mode can only be set by clicking the icon
on the TS.
2. Multiplex mode is the counter part of the bypass mode. This mode
allows the administrator to perform the following operations:
a. Route a single service towards an output channel to create SPTS.
b. Route services towards a single output channel to create MPTS.
c. Route service/s AND stream/s from multiple channels towards a
single output channel to create MPTS.
In Descrambling Settings there are CAM1, CAM2, No Descrambling to choose. Click Apply or
Clear Configuration button on the right side to make the change take effect or clear all
configurations.
