English 9
Starting up the device
Set the trigger into the desired position.
Illustration K
● Position "1 ON": The suction / blowing function is ac-
tivated.
● Position "0 OFF": The device is switched off.
Operation
ATTENTION
Flat pleated filter missing
Device damage
Always work with the flat pleated filter inserted.
Note
Pay attention to the latest part numbers when purchas-
ing and installing filter bags and flat pleated filters.
Information on accessories and spare parts can be
found at www.kaercher.com.
Dry vacuuming
ATTENTION
Vacuuming cold ashes
Device damage
Only vacuum cold ash with an ash pre-separator.
ATTENTION
Defective or wet flat pleated filter
Device damage
Before initial startup, check the flat pleated filter for
damage and replace it if necessary.
Only vacuum with a dry flat pleated filter.
Note
Replace the filter bag in good time, as a filter bag that is
too full could be damaged. The fill degree of the filter
bag depends on the amount of dirt vacuumed. The filter
bag should be replaced more frequently when vacuum-
ing fine dust, sand, etc.
Wet vacuuming
ATTENTION
Wet vacuuming with a filter bag
Device damage
Do not use a filter bag when vacuuming wet.
ATTENTION
Operation with full container
When the container is full, a float switch closes the suc-
tion opening and the device runs at a higher speed.
Switch off the device immediately and empty the con-
tainer.
Note
If the device falls over, the float can also close. To make
the device capable of vacuuming again, set up the de-
vice, switch it off, wait 5 seconds and then switch it on
again.
Blower function
The blower function can be used to clean areas that are
difficult to reach or where vacuuming is not possible,
e.g. leaves in a gravel bed.
Insert the suction hose into the blower connection.
The blower function is now activated.
Illustration L
Interrupting operation
1. Set the trigger to "0 OFF".
The device is switched off.
2. Variant 1: Place the handle of the suction hose in the
intermediate parking position.
Illustration M
Variant 2: Attach the floor nozzle in the parking po-
sition.
Illustration N
Ending operation
1. Set the power switch to "0 OFF".
The device is switched off.
2. Remove the device head.
Illustration B
3. Empty the container.
Illustration O
4. Storage possibility:
Illustration V
Note
The suction hose can be wrapped around the device
head and attached to the device head with the help of
the hose collar.
5. Store the device in a dry and frost-proof room.
Removing the battery pack
Note
During longer work breaks, remove the battery packs
from the device and secure them against unauthorized
use.
● Push the battery packs upwards and remove them
from the device.
Transport
몇 CAUTION
Risk of injury and damage!
Injury or damage due to non-observance of the weight.
Be aware of the weight of the device during transport
and storage.
Manual transport
1. Lift and carry the device by the carrying handle.
Transport in vehicles
1. Secure the device against slipping and tipping over.
Care and service
General care instructions
Clean the device and plastic accessory parts with a
commonly available plastic cleaner.
Rinse the container and accessories with water, as
necessary, and dry them before further use.
Clean the filter box / flat pleated filter
1. Unlock the filter box and fold it out.
Illustration P
2. Remove the filter box.
Illustration Q
3. Empty the filter box into a waste container. In the
case of heavy soiling, tap the filter box against the
edge of the waste container. The flat pleated filter
does not have to be removed from the filter box.
Illustration R
If necessary, clean the flat pleated filter separately.
4. To do this, remove the flat pleated filter from the filter
box.
Illustration S
5. Clean the flat pleated filter under running water. Do
not rub or brush off.
Illustration T
