Je bekijkt pagina 9 van 128
English 9
4 Battery pack (special accessories)
5 Battery holder
6 Carrying handle (foldable)
7 Holder for accessories
8 Casing
9 Spray / suction hose
10 Charger (optional accessory)
11 Union nut
12 Nozzle mouthpiece
13 Lever on the upholstery nozzle
14 Upholstery nozzle
15 Wastewater container with lid, removable
16 Spray / suction hose connection
17 Power switch
Symbols on the device
Initial startup
1. Check hoses for damage before each startup.
Installing accessories
1. Attach the spray/suction hose to the spray/suction
hose connection on the device and click into place.
Illustration B
Note
Remove the spray/suction hose: Press the latch and
pull the spray/suction hose out.
2. Connect the upholstery nozzle to the spray/suction
hose and click into place.
Illustration C
Filling the fresh water reservoir
DANGER
Danger from detergents
Risk of injury and damage
Observe all instructions that are included with the deter-
gents used.
Note
Warm water (maximum 50 °C) increases the cleaning
effect. Check the temperature resistance of the surface
to be cleaned.
Note
Use detergents sparingly to conserve the environment.
● The total filling quantity is a maximum of 1.7 litres.
1. Mixing the cleaning solution: Mix the fresh water and
the detergent in a clean container (concentration as
specified for the detergent). Dissolve the detergent
in the water.
2. Pull the fresh water container vertically upwards and
out by the recessed grip.
3. Pull the container closure upwards and turn it side-
ways or unlock and remove the container lid.
Illustration D
4. Fill the fresh water container with the cleaning solu-
tion.
5. Close the container closure or fit the container lid
making sure that it is firmly seated.
6. Fit the fresh water container down to the bottom of
the device.
Inserting the battery pack
1. Slide the battery pack into the battery holder and
lock it in place.
Charging the battery pack
Note
Read the operating instructions of the charger manufac-
turer and observe the safety instructions in particular!
Note
Please read the operating instructions of the battery
pack manufacturer, especially the chapters on safety in-
structions!
Note
The battery pack is partially charged on delivery.
Charge before use and when necessary.
Note
The battery pack can only be charged when it is re-
moved.
1. Pull the battery pack upwards and remove it.
2. Charge the battery pack according to the operating
instructions of the charger manufacturer and the
battery pack manufacturer.
Operation
Note
Only switch on the device when the fresh water contain-
er and waste water container are installed.
Switching the device on
1. Turn the power switch to position 1 (ON). The suc-
tion turbine and pump start.
Cleaning mode
ATTENTION
Danger from cleaning solution
Risk of damage
Before using the device, check the object to be cleaned
for colour fastness and water resistance in an incon-
spicuous place.
1. Remove loose dirt from the object to be cleaned.
2. Press the lever on the upholstery nozzle to spray the
cleaning solution.
Illustration E
3. Run over the surface to be cleaned in overlapping
paths. Pull the nozzle backwards (do not push).
Note
When the waste water tank is full, a float switch closes
the suction opening and the device runs at a higher
speed.
4. Switch off the device immediately and empty the
waste water container.
Switching off the device
1. Turn the power switch to position 0 (OFF).
Emptying the waste water container
1. Pull the wastewater container vertically upwards
and out by the recessed grip.
2. Unlock and remove the container lid.
Illustration F
3. Empty the wastewater container.
