12 English
Currently applicable EU Directives
2006/42/EC (+2009/127/EC)
2011/65/EU
2014/30/EU
Harmonised standards used
EN IEC 63000: 2018
EN 55014-1: 2017 + A11: 2020
EN 55014-2: 2015
EN 60335-1
EN 60335-2-68
EN 62233: 2008
National standards used
-
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2020/10/01
We hereby declare that the product described below
complies with the relevant provisions of the following
UK Regulations, both in its basic design and construc-
tion as well as in the version put into circulation by us.
This declaration shall cease to be valid if the product is
modified without our prior approval.
Product: Spray retraction device
Type: 1.101-xxx
Currently applicable UK Regulations
S.I. 2008/1597 (as amended)
S.I. 2012/3032 (as amended)
S.I. 2016/1091 (as amended)
Designated standards used
EN IEC 63000: 2018
EN 55014-1: 2017 + A11: 2020
EN 55014-2: 2015
EN 60335-1
EN 60335-2-68
EN 62233: 2008
National standards used
-
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2020/10/01
Technical data
Subject to technical modifications.
Declaration of Conformity (UK)
Puzzi
2/1 Bp
Electrical connection
Battery pack nominal voltage V 36 DC
Degree of protection IPX4
Protection class III
Nominal power W 350
Maximum power W 350
Spray pump power W 4
Device performance data
Fresh water filling quantity l 1,7
Wastewater filling quantity l 2,9
Air quantity (max.) l/s 16
Vacuum (max.) kPa
(mbar)
16,0
(160)
Spray pressure MPa 0,16
Spray pressure (max.) MPa 0,22
Spray volume l/min 0,3
Cleaning solution temperature
(max.)
°C 50
Operating time at full battery
charge - Battery Power 36/50 bat-
tery pack
Minutes 31
Operating time at full battery
charge - Battery Power+ 36/60
battery pack
Minutes 37
Operating time at full battery
charge - Battery Power+ 36/75
battery pack
Minutes 46
Dimensions and weights
Typical operating weight kg 5,8
Length x width x height mm 415 x
205 x
260
Ambient conditions
Ambient temperature (max.) °C +40
Determined values in acc. with EN 60335-2-68
Sound pressure level L
pA
dB(A) 72
Uncertainty K
pA
dB(A) 2
Hand-arm vibration value m/s
2
<2,5
Uncertainty K m/s
2
0,2
