English 17
erate the device at temperatures below 0 °C. ● Protect
the device from rain. Do not store the device outdoors.
● For the purposes of recharging the battery, only
charge the FCV 4 with the FCV 4 charging station.
Symbols on the device
Description of the device
For the illustrations, refer to the graphics page.
Illustration A
1 Self-cleaning button
2 ON/OFF button
3 Mode switch button
4 Handle
5 LED display
6 Lift handle
7 Fresh water tank release button
8 Fresh water tank handle
9 Fresh water tank
10 Replaceable battery cover
11 Flat pleated filter
12 Sponge filter
13 Dirty water tank cover
14 Dirty water tank release button
15 Dirty water tank handle
16 Dirty water tank
17 Floor nozzle cover release button
18 Floor nozzle cover
19 Cleaning roller
20 Cleaning roller storage
21 Cleaning brush storage
22 Charging and cleaning station
23 Cleaning brush
24 * Detergent RM 536 (30 ml)
25 * Detergent RM 538N (500 ml)
* optional
Installation
KÄRCHER Home & Garden App
With the KÄRCHER Home & Garden app, you benefit
from the following advantages when using your device:
● Application tips & expert knowledge
● Product information, overview of accessories and
operating instructions
● Support and service contact
● Online shop - exclusive offers and much more
Scan the code on the packaging or download t
he
K
ÄRCHER Home & Garden app from your app stor
e
a
nd conveniently register your product.
Installing the device
1 Insert the handle into the basic unit until it audibly
clicks into place.
Note
In the event that the product must be returned, please
disassemble the handle. Press the spring to release the
handle with a tool (like a screwdriver) and lift the re-
leased handle from the appliance.
Illustration B
Initial start-up
Charging process
1. Plug the charging cable of the charging and clean-
ing station into the socket.
2. Place the device into the charging and cleaning sta-
tion. The LED display shows the current charging
state of the battery.
Illustration C
The battery is fully charged after 5 hours. After 10
minutes of full charge, the LED display turns off.
Filling the fresh water tank
1. Remove the fresh water tank from the device, by
grasping the handle of the fresh water tank and
pressing the release button at the same time.
Illustration D
2. Open the tank cap and turn it to the side.
Illustration E
3. Fill the fresh water tank with cold or lukewarm ta
p
water
.
4. Add Kärcher detergent to the fresh water tank.
ATTENTION
Overdosing or underdosing of the detergent or care
agent results in poor cleaning results.
Follow the dosage recommendations for the detergent
or care agent.
5. Close the tank cap.
6. Push the fresh water tank into the device until it au-
dibly clicks into place. The fresh water tank must sit
firmly in the device.
Illustration F
Operation
General information on operation
ATTENTION
Moisture
Material damage to sensitive floors
Check the surface to be cleaned for water sensitivity at
an inconspicuous location before using the device.
The warning of not laying the device flat
is located on the back of the device.
The warning of not rinsing the floor noz-
zle under running water is located on the
top of the floor nozzle.
The warning of not rinsing the charging
and cleaning station under running wa-
ter is located on the top of the charging
and cleaning station.
