English 7

4 Dust container

5 Filter cover

6 HEPA filter (2x)

7 Steel net filter

8 2-in-1 crevice nozzle

9 Charging cable

10 Charger

11 Storage bag

Charger

몇 WARNING

● Only charge the appliance using the original charger

enclosed or with a charger approved by KÄRCHER.

Use the following adapter:

● Appliance type

CVH Anniversary Edition: 1.198-355.0

9.796-743.0

Charging the vacuum cleaner

Note

● The appliance does not work during the charging

process.

● The charging time is approx. 3 - 4 hours.

● The appliance must be fully charged before first use.

1. Insert the two USB plug connectors of the charging

cable into the charging port of the applience and

charger.

2. Plug the charger into the power socket.

Illustration B

3. When the charging process is complete, unplug the

power plug from the power socket.

Operation

● Press the ON/OFF button to start vacuuming up

dust / dirt.

Illustration C

● 2 suction modes are available with full speed and

energy saving modes.

LED indicator

The table below describes the meanings of the LED in-

dicators (green and red) on the device:

Standard accessories

● Attach the 2-in-1 crevice nozzle to clean uphol-

stered furniture, mattresses, laced curtains, etc.

Illustration D

Illustration E

1 This is used for cleaning delicate objects with care,

e.g. bookcases, handicrafts, etc.

2 This is used for cleaning joints, grooves between

doors and windows, tiny slits, etc.

Warranty

The warranty conditions issued by our relevant sales

company apply in all countries. We shall remedy possi-

ble malfunctions on your appliance within the warranty

period free of cost, provided that a material or manufac-

turing flaw is the cause. In a warranty case, please con-

tact your dealer (with the purchase receipt) or the next

authorised customer service site.

(See overleaf for the address)

Further warranty information (if available) can be found

in the service area of your local Kärcher website under

"Downloads".

Transportation

The battery has been tested in accordance with the rel-

evant rules for international transport and can be

transported / shipped.

Storage

Note

● Store the appliance in a dry room.

● Consider the weight of the appliance when storing it.

1. After use, store the vacuum cleaner, charging cable,

charger and 2-in-1crevice nozzle in the storage bag.

2. Clos

e the storage bag with the cord.

___

Illustration M

Care and maintenance

Note

● Use the appliance only when all filters and the dust

container are installed.

● Defective filters and filters that can no longer be

cleaned must be replaced.

Before doing any work on the appliance:

1. Switch off the appliance.

2. Unplug the power supply from the power outlet.

Cleaning the filter set and the dust container

ATTENTION

Incorrect cleaning of the HEPA filter

Damage to the HEPA filter

Do not clean the HEPA filter in a washing machine.

Do not dry the HEPA filter with a hair dryer.

ATTENTION

Health risk

HEPA filters that are not completely dry when installed

in the device can be a breeding ground for spores and

mould.

Make sure that the HEPA filter is completely dry on in-

stallation.

The HEPA filter ensures clean exhaust air.

● Clean the HEPA filter if it is visibly dirty.

● Replace the HEPA filter if it is visibly damaged.

● We recommend replacing the HEPA filter every 6

months based on your use of the device.

1. Unlock the dust container.

Illustration F

2. Unplug the filter set from the dust container. Turn the

filter cover counterclockwise. Remove the filter cov-

er, unplug the HEPA filter from the steel filter.

Illustration G

LED Description

LED light up continuously

green

Device is switched on

The battery power is full

charged

LED flashes red The battery power is low

The battery power is

charging
