Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGIUM. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity.
12 TKG VT 1024R 160113
Assembly page 12/37
Fax +32 2 359 95 50
ASSEMBLY
1. Unscrew the screws on stand A and stand B and place stand A on stand B to form an X-base.
2. Attach the 4 small feet onto the ends of stand A and stand B.
3. Place the lower pipe (13) with pipe support on the X-base and fix it with the four screws provided.
4. Loosen and remove the pipe connector (12) from the lower pipe (13). Slide the plastic base cover
over the lower pipe on the base. Extend the upper (inner) pipe (11) and slide the pipe connector
(12) over the upper pipe onto the lower pipe and tighten.
5. Unscrew the knurled bolt (10) but make sure that the hex nut remains attached on the inside.
Attach the motor (6) with speed regulator (8) onto the upper pipe (11) and tighten the knurled bolt
(10).
6. Loosen the guard mounting ring (3) from the motor housing (6).
7. Position the rear guard (4) firmly against the motor housing (6) in such a way that the small hole for
the reinforcement screw is at the bottom of the rear guard, and fasten by turning the guard
mounting ring (3) clockwise tightly.
8. Push the blade (2) along the motor shaft (5). Fasten it firmly with the cap by turning counter
clockwise.
9. Hang the front guard (1) to the rear guard (4) with the position fixer provided at the front guard rim,
and then clamp together with the clips provided.
10. To ensure that it is impossible to have access to the fan blade without using a tool, a screw is
provided with this appliance in order to attach both parts of the mesh guard together. This screw
must be tightened with the appropriate hex nut on the lower part of the guards. We will not be
responsible for any injuries in case this screw had not been tightened before using the appliance.
11. To change the height, loosen the pipe connector (12) and slide the upper pipe to a suitable height.
Then tighten the pipe connector (12) again.
OPERATION
You can operate the fan by the panel control or the remote control in 10 meters distance.
The table below shows which switches perform which speed and wind functions.
Main control panel &
Remote Control switches
Indicator
Lights
Features
OFF
POWER
Standby mode. The fan is ready to use but
has not started operating yet.
ON/SPEED
LOW
MED
HIGH
Press Once –
Low Wind speed setting
Press twice –
Medium Wind speed setting
Press three times –
High Wind speed setting
OSC
OSC
Press Once –
The Fan head will oscillate
When pressing again –
The Fan head will be fixed in one direction only
