Kali Audio SM-5 Users’ Guide 19
Mounting
Kali Audio recommends using Triad-Orbit®’s SM-KB1 to mount the SM-5. This mount is sold most
places where SM-5s are available. The SM-5 includes 8 x M6 25mm panhead hex screws and 8 x rub-
ber washers to be used with the SM-KB1. To install the SM-KB1:
1. Remove the 4 screws that come installed in the top and the bottom of the SM-5. Discard these or
save them in case you want to take the SM-KB1 off at some other time.
2. Slide the SM-KB1 over the speaker. On the top and bottom, you should be able to see through the
holes on the SM-KB1 to the holes on the SM-5.
3. Install the rubber washers on the M6 x 25mm screws. Put the washer as close to the screw head as
possible.
4. Use the screws to secure the SM-KB1 to the SM-5. Hand tighten them so that the rubber washer is
fully engaged.
If you’d like to use a different mount, you will need a mount with a 4.25-inch (108mm) x 2-inch
(50.8mm) hole pattern. The mount must also be able to hold the SM-5’s 21-lb weight.
Whichever mount you choose, follow the instructions provided by the mount’s manufacturer. Kali
Audio is not responsible for damage or injury resulting from failing to follow the instructions included
with the speaker mount.
Fig. 1: Top of the SM-5 showing mount-
ing hole position and spacing.
Fig. 2: Bottom of the SM-5 showing
mounting hole position and spacing.
Fig. 3: SM-5 with KP-1 mount and SW-1
swivel accessory mounted.
