Kali Audio SM-5 Users’ Guide 15
Inputs and Controls
DIP Switches
The DIP switches on the back of the SM-5 allow for control of the speaker without the direct use of
Kali Control Panel.
Each set of dip switches controls one aspect of the speakers performance, independent of the oth-
er switches. Switches 1-3 control the boundary compensations EQs. Switch 4 controls whether the
speaker is playing one of Kali’s boundary EQs or a user EQ that you have programmed. Switches 5 and
6 control the LF Trim. Switches 7 and 8 control the HF Trim. For this reason, the explanations of the
different dip switch settings will only reference the set of switches currently applicable.
Switches 1-3: Boundary Compensation EQs
Position 1: Free Space/User Preset 1
The Speaker is on a monitor stand, at least .5 meters (about 20 inches) away
from any walls. This is the ideal position for the loudspeaker.
Switch 1: DOWN
Switch 2: DOWN
Switch 3: DOWN
Position 2: Speaker Stand, Close to a Wall/User Preset 2
The speaker is on a monitor stand, and is less than .5 meters (20 inches) from a
wall, without being right against the wall.
Switch 1: UP
Switch 2: DOWN
Switch 3: DOWN
Position 3: Speaker Stand, Against a Wall/User Preset 3
The speaker is on a monitor stand, and is as close to a wall as possible without
pinching any cables.
Switch 1: DOWN
Switch 2: UP
Switch 3: DOWN
The boundary compensation EQs help to mitigate the effect of various common room elements on the
speaker’s frequency response. The boundary compensation EQs can be helpful to increase out-of-
the-box performance, but they are not a substitute for proper room calibration. While measuring your
room and applying calibration, we recommend turning all boundary compensation off.
Select the boundary EQ that most closely matches your use case. If two or more boundary EQs might
work, try both, and select the one that you like the best.
