22
EN
• Align the seal 5 with the hole in the
door and place in it, adjusting the
step of the seal to the step in the
hole.
Locking the water dispenser lever
Water tank disassembly
To prevent children to taking water you
can lock the water dispenser lever.
• To unlock the lever 2, pull the switch
1 to the right.
• Push the switch 1 with your finger to
the left to lock the water dispenser
lever 2.
The lever is locked.
Hold both sides of the tank 3 with hands
and pull the tank assembly off the door
slightly in the direction indicated with an
arrow 4.
Remove the sealings and re-install
them according to the following steps:
• Rotate counterclockwise to remove
the water valve assembly 6 from the
water tank for cleaning.
• Press lightly on the flange of the
water tank lid upward and the lid can
be detached from the water tank.
Separate the other side in the same
way. The reservoir and its lid can be
cleaned after disassembly.
• Place the tank assembly at a 45°
angle to the door. Press lightly on the
outer edge of the water tank to slide it
into the door.
• Install the water valve by screwing it
clockwise after cleaning. When
installing the reservoir lid, install one
side first (do not push it all the way
down), then install the other side.
Press down firmly on the edges of
the tank cap until they are in contact
with the tank.
MAX
2L
-22 04
1
2
5
6
3
Attention! The transparent silicone
sealing parts of the water valve
could be brought out meantime
when removing the water tank.
!
4
