• Hang the telescopic column 4 to the hood’s body
and to the wall hanger using appropriate screws.
• Place the hanger 5 of the top telescopic column 4
at the level of mounting holes and install the
hanger.
• Connect the hood to the power supply network.
Mount a logo plate to the masking cover1 2 using the
attached fastening parts.
• Align the so that the mounting masking cover 2
holes are at the bottom.
MOUNTING OF THE LOGO PLATE
• Install on the front side of the logo plate 1
masking cover by inserting its feet into the 2
mounting holes.
• On the mounted hood attach the the masking 3
cover and telescopic column on it.2 4
• Pull out the telescopic column 4 on the
demanded height. Mark the level of the mounting
holes. Remove the telescopic column.
• Fix the inside the masking cover logo plate 1 2
using the supplied rubber spacers (if included),
tight the screws into the feet of the logo plate 1.
MOUNTING OF THE TELESCOPIC COLUMN
5
4
2
3
1
