Page 6
GUI - Graphical User Interface Overview
The Live Production Software is operated via an innovative, touch screen user interface,
perfectly tuned for live streaming production.
It was designed to fulfill all the requirements of a live streaming production in the easiest, most ecient
and user-friendly way. It allows a high level of sophistication, creative freedom, operational flexibility
while maintaining a perfect control of every aspect of the production at all times.
The GUI is designed to allow the control of processes, functionalities and workflows in the most logical and
practical way. Its layout is divided into 3 main, horizontal sections, containing logically related, operational
elements and functions.
1. PRODUCTION LAYOUT section - on top
2. PGM & CAMERA SWITCHING section - in the middle
3. CONTENT MANAGEMENT & SETTINGS section - at bottom
At the very bottom is an additional information bar displaying some helpful info on system status.
PRODUCTION LAYOUT
section
PGM & CAMERA SWITCHING
section
CONTENT MANAGEMENT
& SETTINGS section
Info bar
PGM
OUTPUT MONITOR
CAMERA
MONITORS/SWITCHES
NOTE:
As you will learn the PGM and Live Camera monitors/switches desktop areas (marked yellow in the above image)
are occasionally used to display certain control elements, logically related to various functionalities. As you learn
the GUI you will quickly understand how it all makes perfect sense and allows for incredible speed with which you
can work with the ProHD Studio SW.
SOFTWARE START
Start the ProHD Studio SW application in a Windows OS usual way
by double clicking its desktop icon.
