LED displays BVNG650-…
The two displays LED1 and LED2
at the bus line rectier indicate
functions for operation and possible
faults in the In-Home bus. The fol-
lowing table indicates the possible
displays.
Display LED1 “Operation“
LED ashes evenly
(System ramp-up)
0,3s 0,3s
0,3s 0,3s 0,3s 0,3s 0,3s 0,3s 0,3s 0,3s etc.
LED ashes short on, long off
(Operation display, system is functional)
1s
20ms 1s 20ms 1s 20ms etc.
LED ashes short on, long off
(Programming mode active)
0,3s 2s
0,3s 2s 0,3s etc.
LED remains alight
(Plug+Play programming is active)
Display LED2 “Fault“
LED ashes long on, short off
(Own address incorrect)
2s 0,3s 2s etc.
LED ashes long on, short off short on,
short off, long on
(More than 31 users in the line)
2s 0,3s 0,3s 0,3s 2s etc.
LED remains alight
(Address error at other BNG/
BVNG650-…)
LED ashes evenly
In multiple line systems, more than one
ZBVG650-… connected
0,3s 0,3s 0,3s 0,3s 0,3s 0,3s 0,3s 0,3s 0,3s 0,3s etc.
LED ashes unevenly
Unsuitable device connected in
Plug+Play mode
0,3s
0,3s 0,2s
2s 0,3s
0,3s 0,2s etc.
LED ashes evenly
No BTLM/BTLE connected in Plug+Play
mode
2s 2s etc.
137
