5

Conguration of In-Home: Audio

The basic installation of

In-Home-Bus: Audio takes place as

a single-line system. Within this line,

the users are installed on the bus

cores. A maximum of 31users may

be connected to one line. Users are

classied as devices occupying an

address within the bus. If more than

31users are required, additional

lines must be congured. Apart from

a few exceptions, all the devices

have an assigned address. Up to

15lines each with 31users can be

congured (in theory a maximum of

465users).

Power supply

The nerve centre of any line is the

bus line rectier, which controls the

entire function of the system. The

bus cores are connected to the bus

line rectier.

Conductor material

Telecommunication or light current

conductors can be used for instal-

lation:

J-Y(St)Y Twisted pair conductors,

shielded

CAT Network cable

A2Y(St)2Y Buried telecommunica-

tion cable

YR Light current conductor

0.8mm core diameter

The In-Home bus must be installed

on one pair of cores when using

J-Y(ST)Y, and when using a YR

conductor, on two YR cores posi-

tioned side by side. Using J-Y(ST)Y

conductors reduces the likelihood of

interference.

Single line system

Conductor length

Conductor material J-Y(ST)Y

or YR conductor with 0.8mm

diameter:

• max. 300m from the bus line rec-

tier to the most distant door station

• max. 300m from the bus line

rectier to the most distant bus

telephone.

Conductor material J-Y(ST)Y

or YR conductor with 0.6mm

diameter:

• max. 150m from the bus line rec-

tier to the most distant door station

• max. 150m from the bus line

rectier to the most distant bus

telephone.

A maximum of 1500m of instal-

lation cable may be laid within the

line.

max. 300 m/984 ft. max. 300 m/984 ft.
