containing steel cabinets is to be
used as an archive, a connection
that is already weak anyway could
be negatively affected by this.
Repeaters
Repeaters are used to repeat re-
ceived wireless telegrams and to
thus increase the system range
and the possible distance between
the transmitter and the actuator. It
is useful to use a repeater roughly
halfway between the actuators and
sensors whose communication is
to be improved or whose wireless
range is to be increased.
The installation engineer can
activate the repeater function with
a mains supplied eNet device on the
radio link. Alternatively, a separate
repeater can be set.
No more than two devices should
work as a repeater within an eNet
system, so as not to excessively load
the wireless channel.
Using a separate repeater
A separate repeater (no longer
available for reorder) supports two
types of functions:
When simply used in the system,
it repeats all the received wireless
telegrams – just like the wireless
actuators with a repeater function.
The repeater can also be directly
connected to wireless transmit-
ters. In this situation, it only re-
peats the telegrams from those
wireless transmitters that are
“personally known” to it. This
operating mode leads to far less
wireless traffic and is preferable
to repeating all the wireless tele-
grams.
Activating the repeater function
in an eNet device
Mains-operated eNet devices – i. e.
actuators or a universal transmit-
ter, for example – have a repeater
function that can be activated by
the installation engineer if nec-
essary. Devices with an activated
repeater function repeat all the re-
ceived wireless telegrams, regard-
less of whether they are intended
for them or not. One wireless tele-
gram can be repeated a maximum
of two times within an installation.
This ensures that a telegram is only
repeated by a repeater once.
… with the eNet diagnostic device
The repeater function can also be
activated or deactivated without
the eNet server – by using the di-
agnostic device:
• The eNet device is first put into
Programming mode. The eNet
diagnostic device establishes
the connection automatically.
• The repeater function can now
be activated or deactivated us-
ing the diagnostic device.
… with the eNet server
Activation is carried out using
the “Repeater mode” device pa-
rameters, which are changed in
the eNet SMART HOME connect
commissioning interface using
the eNet server.
4. TROUBLESHOOTING IN
SYSTEMS WITH REPEATERS
In a system containing eNet repeat-
ers, there may also be an error in
the repeaters’ function. A check
should take the following aspects
into account:
• Is the repeater still available in
the system?
• Is the repeater still in its original
position, and is it being supplied
with power around the clock?
• Has the repeater been blocked
with shielding materials?
• Is the repeater connected to
the eNet devices whose wire-
less signal it is supposed to be
repeating?
5. CONNECTION WITH THE
eNet SMART HOME app
If the connection from a smart-
phone or tablet to an eNet system
is interrupted, the aspects should
be checked:
• Is the smartphone or tablet
logged onto the same network
(or WLAN) as the eNet server?
• Has the correct eNet server been
selected in the eNet SMART
HOME app? There may be several
eNet servers in a single network.
Check the serial or IP address of
the selected eNet server.
• Are the username and password
in the eNet SMART HOME app
correct?
• Is there a WLAN connection, and
are the selected SSID and the
WLAN password correct?
• How many smartphones and tab-
lets are already logged onto the
eNet server?
Observe the system limits.
eNet repeater as an
adapter plug*
* No longer available for reorder.
147146 eNet _ Service and diagnostics
