Create a building structure
Create areas and rooms
Add and configure devices
From the device search or catalogue
Create connections
Connect sensor channels to actuator channels
Program connections
figure settings and activate addi-
tional functions such as the switch-
on or switch-off delay.
In the next step, permanent device
connections between transmitter
and actuator channels are creat-
ed in the SMART HOME connect
commissioning interface. These
device connections are not shown
in the app and cannot be changed.
Installation engineers can thus use
device connections of this type to
create a stable and reliable basic
eNet installation that cannot be in-
tentionally or accidentally modified
by the customer. Connections be-
tween transmitters and actuators
also remain active if the server is
switched off or removed from the
system.
End customers can link transmit-
ters and actuators with the app
using If-Then rules. But for this to
happen, the sensor channels must
be configured for this use during
the commissioning process.
Programming connections
As a last step, the settings and
connections made must be pro-
grammed in the devices. Battery-
operated devices (e. g. hand-held
transmitters) must be woken up for
this by means of brief operation on
the device. During the installation
process, battery-operated devices
do not remain permanently acces-
sible via wireless contact. They only
activate their wireless capabili-
ty briefly and at regular intervals
so that their batteries do not go
completely flat. Battery-operated
devices shut down their program-
ming capability and switch back
to Power-saving mode as soon
as eNet SMART HOME connect is
closed.
Settings with
eNet SMART HOME app
An eNet system handed over by the
installation engineer can be mod-
ified by the end customer to in-
clude scenes, timing functions and
If-Then rules and adapted to suit
their individual needs at any time.
Individual device parameters such
as run-on times can be changed
in the app too. It is also possible
to add partner systems, e.g. tado°
Professional. Moreover, individual
device parameters, e.g. run-on
times in the app, can be changed.
Examples of timing functions:
• The lights in the kitchen, garden
and living room are automatical-
ly switched on when the sun sets
(Astro function)
• The lights on the ground floor and
in the garden are switched off at
midnight
• The roller shutters on the ground
floor open when the sun rises, but
not before 6 am
Examples of If-Then rules:
• If the light intensity on the out-
side motion detector falls below
35 lux at twilight, then the outside
lighting switches on
• If scene button 1 is pressed on
the wall transmitter at the bed-
side in the bedroom, then all the
lights in the house and garden
are switched on
The devices are then assigned to
the room they were installed in
(device location). The individual de-
vice channels are each assigned to
the room they “have an effect on”
(channel location). The channel
location is shown in the app later
on. The device location of a 4-gang
DRA switching actuator may, for
example, be “Cellar”, while its ac-
tuator channels may be assigned
to the living room, bedroom, work-
ing room and bathroom channel
locations.
The device parameters can be used
to change the operating mode, con-
Server commissioning process – overview
135134 eNet _ Planning and commissioning
